AccuSet2™ On-The-Go Seed Depth Adjustment
Units equipped with a Quick Depth Adjust frame are available with the ground-breaking AccuSet2™ on-the-go seed depth adjustment option.
With ever-changing moisture conditions from field-to-field, and even within the same field, you now have the ability to "bump" your seeding depth accurately, from the seat of the tractor, allowing you to reach the moisture with ease.
Use Your Smartphone to Set Your Depth
With the incorporation of smart hydraulic cylinders, the AccuSet2™ option allows you to set the seeding depth of your QDA drill from the tractor seat with a smartphone. The AccuSet2™ option will let you obtain the best seed depth setting to maximize seedling emergence, on-the-go, in varying soil and moisture conditions.
Independent Bander Adjustment
- The 3335QDA and 3545QDA PHD™, when equipped with PLX™ Openers and AccuSet2™, allows Operators to adjust the operating depth of the Mid Row Bander® Fertilizer Applicators independently of the seed openers.
- This is possible by taking advantage of the PLX™ one-to-one design and separate control features on the AccuSet2™ app.
AccuSet2™ Availability & Range
| 3335QDA™ |
AccuSet2™ Depth Adjustment |
Range of Depth Adjustment |
| PLX™ |
optional |
¾" |
| PLS™ |
optional |
1¼" |
| PLDS™ |
optional |
½" |
In the event of a failure, the seeding unit can easily be set into standard QDA mode. A hand-ball valve located on the hitch allows the operator to isolate the AccuSet2™ option and use the shims to set frame depth.
