| MODEL |
XR771-90 |
XR771-70 |
XR751-90 |
XR751-70 |
| Working Width |
90' |
70' |
90' |
70' |
| Rows of Tines |
7 |
7 |
5 |
5 |
| Transport Length |
61' 8" |
51' 8" |
61' 8" |
51' 8" |
| Transport Width |
14' 10" |
14' 11" |
14' 10" |
14' 11" |
| Transport Height |
13' 8" |
13' 8" |
13' 8" |
13' 8" |
| Weight* |
19,400 lb |
15,600 lb |
18,600 lb |
14,800 lb |
| GENERAL SPECS (all sizes) |
XR771 |
XR751 |
| Tires |
Main Frame: Standard 21.5L x 16.1SL
Wings: Standard 13.5L x 15FI Dual |
Main Frame: Standard 21.5L x 16.1SL
Wings: Standard 13.5L x 15FI Dual |
| Tines - Standard |
1/2" x 22" |
5/8" x 26" |
| Tine - Options |
1/2 x 22" carbide infused tines
on first 2 rows or all 7 rows |
5/8 x 26" carbide tips |
| Boom Clearance |
fixed 28" |
fixed 28" |
| Harrow Sections |
7 Row, 10' wide sections |
5 Row, 10' wide sections |
| Main Boom Tubing |
70': 8" x 8" x 0.250" wall
90': 8" x 8" x 0.375" wall |
70': 8" x 8" x 0.250" wall
90': 8" x 8" x 0.375" wall |
| Wheel Standards |
Cart Frame: triple-lip seals on 6,000 lb hubs
Wing: triple-lip seals on 5,000 lb hubs |
Cart Frame: triple-lip seals on 6,000 lb hubs
Wing: triple-lip seals on 5,000 lb hubs |
| Effective Tine Spacing |
1.43" |
2.4" |
| Hitch Capacity |
Up to 5000 lb for on-board granular application tank (application and product) |
| Remotes Required |
Four standard (optional Hydraulic Jack tees into the latch circuit) |
| Tine Angle Control |
Standard - Hydraulic, Adjustable from 45° to 90° |
| Section Angle Control |
Standard - Hydraulic |
| Adjustable Downforce |
Standard - Manual Control
Optional - In-Cab Remote Control |
| Power Requirements |
4-5 H.P. per foot |
5 H.P. per foot |
*All weights & transport dimensions are estimates & are subject to change. Every effort has been made to ensure that the information is accurate/current at the time of production.
