Mid Row Bander® III

1

Floating Carbide Scraper

The floating inside scraper maintains a good furrow in a wide range of seeding conditions.
2

Hydraulic Actuation

The hydraulically controlled Mid Row Bander® applicators are synchronized with the seed arms or shanks for efficient in-field operation.
3

Double-Tapered Roller Bearing Hub

You can expect a long service life with the high capacity hub and spindle assembly.
4

Parallel Link Arrangement

The MRB® body is mounted on parallel arms for a constant disc attack angle and seed boot / liquid tube orientation regardless of its operating depth
5

Simple Depth Adjustment

Shims on the hydraulic cylinder are used for setting the depth.
6

Hardy Coulter Arm Pivots

The MRB® arm pivots are equipped with needle bearings and grease-able pins for long service life.
7

Fine Scraper Position Adjust

The position of the scraper relative to the edge of the disc can be adjusted in fine increments.
8

Coarse Scraper Position Adjust

Adjust the whole scraper/boot assembly to maintain the optimal scraper-to-disc position as the disc wears.
9

Combo-Boot

The versatile combo-boot allows you to select between dry, liquid, or anhydrous forms of nitrogen application.
10

Long Wearing Coulter

The large single bevel boron steel coulter is set to open the soil just enough to deposit the fertilizer.
11

Strong & Durable Cast Components

The MRB III operates in the most challenging agricultural environments without breaking or bending. Well-designed castings are machined to exact specifications.
12

Scraper Pressure Adjustment

the pressure of the carbide scraper on the disk can be easily set to match soil conditions for optimal results.
MRBIII
