| Model |
GC1200 |
| Tank Capacity |
1,200 bu |
| Max Content Capacity |
82,000 lb |
| Cart Weight, Empty |
15,300 lb |
| Est. Loaded Tongue |
3,200 lb |
| Auger Size |
18" |
| Hitch Type |
Single |
| Min. Tractor H.P. |
200 hp |
| Tire Options |
21.5L x 16.1 14-Ply Rib Imp.
21.5L x 16.1 14-Ply Lug |
| Roll Over Tarp |
optional |
| Loadcell Scales |
optional |
| Unloading Rate, PTO |
350 bu/min @ 800 PTO rpm |
P.T.O. Options
There are four P.T.O. shaft options with the 1200 Grain Cart:
- Standard PTO Shaft, 1.75" x 20 Spline - Working range if from 30" to 47" long. This shaft works in most cases.
- Extended PTO Shaft, 1.75" x 20 Spline - Working range is from 32.5" to 52" long. This option is required in uneven terrain (extreme hills) and with certain tractor models. The tractors affected (ex. CaseIH STX QuadTrac) have a larger distance than average between the pto output shaft and the drawbar pin. This effectively puts the grain cart further away from the tractor.
- PTO Drive, 38 mm x 8 Spline
- PTO Drive, 1.75" x 6 Spline
